CSR FE Analysis v2.5


CSR FE Analysis software uses finite element analysis to perform direct strength and fatigue assessment of ship structures for compliance based on the IACS January 2015, January 2017, January 2018, January 2019, January 2020, January 2021, January 2022 and January 2023 versions of the Common Structural Rules for Bulk Carriers and Oil Tankers. The January 2015 Rules came into force on 1st July 2015, the January 2017 Rules are effective from 1st July 2017, the January 2018 Rules are effective from 1st July 2018, the January 2019 Rules will be effective from 1st July 2019, the January 2020 Rules will be effective from 1st July 2020, the January 2021 Rules will be effective from 1st July 2021, the January 2022 Rules will be effective from 1st July 2022, and the January 2023 Rules will be effective from 1st July 2023.

This software supersedes the CSR BulkCheck and TankCheck Stage 2 software for ships designed to comply with these new Rules.

Picture of CSR FE Analysis v2.5
Using CSR FE Analysis, the ship structural and fatigue assessment is integrated within the design phase.
This greatly increases efficiency during the design process and therefore significantly reduces workload.


CSR FE Analysis features:
  • An intuitive analysis workflow to enable finite element analysis complying with the CSR January 2015, 2017, 2018, 2019, 2020, 2021, 2022 and 2023 Rules
  • An interface with the Nastran and Patran finite element modeling tools
  • Minimum data input and accurate output results
  • Automated loading generation
  • A system to rapidly identify areas of concern and the design modifications that may be required

CSR FE Analysis software is fully integrated with MSC Software's Patran and requires a licensed version of Patran 2013 or higher in order to run.

To license CSR's foundation technology (based on MSC Patran) for the CSR Software, please send your request to support@csrules.com

How to download:


To download any of the CSR Software products from the download section below, you need to be a registered user and be logged into the website.  To do this, select Log in from the top right hand corner of the website where you can either log in or register as a new user.
Alternatively, click on the
download button and you will be automatically taken to the login / register screen.





Current rating is 4.14. Total votes 7.
CSR FE Analysis v2.5
Picture of CSR FE Analysis v2.5
CSR FE Analysis v2.5 installation file
CSR FE Analysis EULA

CSR FE Analysis End User License Agreement (EULA)
CSR FE Analysis Fact Sheet English

Fact sheet providing descriptive highlights of the CSR FE Analysis software product (English version)
CSR FE Analysis Fact Sheet Chinese

Fact sheet providing descriptive highlights of the CSR FE Analysis software product (Chinese version)
CSR FE Analysis Fact Sheet Japanese

Fact sheet providing descriptive highlights of the CSR FE Analysis software product (Japanese version)
CSR FE Analysis Fact Sheet Korean

Fact sheet providing descriptive highlights of the CSR FE Analysis software product (Korean version)
